Introduction to Stainless Steel pall Ring Packing: Metal pall Ring is an efficient packing widely used in chemical, environmental protection, refining and other fields. Its design and performance make it an important filling material in tower interiors. Below, we will provide a detailed explanation of the metal ball ring from the aspects of structural characteristics, application cases, and performance data.   The structural characteristics of stainless steel pall rings: Metal pall rings are a new type of filler designed and improved based on traditional Raschig rings. It adopts a double-layer wall structure, with multiple uniformly distributed windows on the ring wall. These windows not only increase the specific surface area of the packing, but also improve the mass transfer efficiency between gas and liquid. At the same time, the height to diameter ratio of the metal ball ring is usually controlled within a certain range. This design enables the packing to form a more uniform distribution inside the tower, reducing short circuits and wall flow phenomena in the airflow.   Application case of stainless steel pall rings: In the chemical industry, metal pall rings are widely used inside various towers, such as absorption towers, distillation towers, extraction towers, etc. Taking the distillation tower of a large refinery as an example, the tower originally used traditional Raschig rings as packing, but during operation, it was found that the purity of the product at the top of the tower could not meet the design requirements. Later, the factory decided to use metal ball rings to renovate the tower. After the renovation, the purity of the tower top product has been significantly improved, and the pressure drop inside the tower has also been significantly reduced, thereby improving the energy efficiency of the entire production process. In addition, metal ball rings also play an important role in the wastewater treatment process in the field of environmental protection. A certain sewage treatment plant used metal Bao'er rings as the packing material for the bioreactor when treating industrial wastewater containing high concentrations of organic matter. Due to its excellent mass transfer performance and large specific surface area, metal Bao'er rings provide a favorable environment for the growth and reproduction of microorganisms. After a period of operation, the wastewater treatment efficiency of the factory has been significantly improved, and the effluent quality has reached the national discharge standards.

The specifications of ceramic corrugated structured packing are divided into 700Y, 450Y, 350Y, 250Y, 150Y, etc. Different specifications correspond to different product dimensions in terms of length, width, and height.   When consulting ceramic corrugated structured packing, customers generally want to know the specific surface area, bulk density, porosity, inclination angle, pressure drop, theoretical plate number, hydraulic diameter, liquid load, factors and other parameters of different types of products. The length, width, and height parameters, even for the same type of ceramic corrugated filler, have different sizes. The tower diameter varies under different operating conditions, and the required length, width, and height are also different.   The function of ceramic corrugated structured packing Due to the unique structure of ceramics, they have good hydrophilicity. The extremely thin liquid film and inclined and tortuous airflow channels can promote the flow of airflow without blocking it, making ceramic fillers compatible with metal fillers. However, their corrosion resistance and high temperature resistance cannot be compared with metal fillers. The surface structure has good wettability, which can accelerate the flow of liquids and minimize the amount of retained liquid in the filler. Thereby reducing the chances of overheating, polymerization, and coking.   The different inclinations can be divided into X-shaped and Y-shaped. X-shaped inclination angle of 300, Y-shaped inclination angle of 450. The X-type pressure drop is relatively small, while the Y-type mass transfer performance is good. To balance pressure drop and mass transfer performance, holes can be opened on the plate. Due to the lack of significant amplification effect of regular packing, its surface roughness is superior to the unique corrosion resistance of the material, and it is used in mass transfer processes such as distillation, stripping, absorption, and extraction in petrochemical industry. Have you learned about the length, width, and height specifications of ceramic corrugated regular packing through the above introduction

Why is CPVC Teller rosette ring used for environmentally friendly high-temperature exhaust gas treatment？ CPVC Teller rosette ring is a powerful assistant for environmentally friendly high-temperature waste gas treatment. In the field of environmental protection, waste gas treatment is a crucial task. Especially in the treatment of high-temperature exhaust gas, it poses severe challenges to technology and equipment. And CPVC Teller rosette ring has become a powerful assistant in the field of environmental protection and high-temperature waste gas treatment due to its advantages and excellent performance.   CPVC Teller rosette ring has high temperature resistance. In the treatment process of high-temperature exhaust gas, ordinary materials often cannot withstand the test of high temperature and are prone to deformation, aging and other problems. The flower wreath filling is made of special chlorinated polyvinyl chloride material, which can withstand high temperatures stably for a long time, ensuring the normal operation of exhaust gas treatment equipment in high temperature environments. This characteristic has made it widely used in industries with severe high-temperature exhaust emissions, such as chemical, metallurgical, and power industries.     Has good chemical stability. In the process of exhaust gas treatment, various chemical substances are often encountered, which may cause corrosion to the packing and affect its treatment effect. However, it has excellent tolerance to most chemicals, is not prone to chemical reactions, and can effectively ensure the long-term stable operation of exhaust gas treatment systems. It can effectively resist acid and alkali corrosion, providing reliable protection for exhaust gas treatment.

The installation and acceptance of internal components and packing materials for methanol separation tower, distillation tower, methanol removal tower, dehydration tower, and solvent removal tower have been successful.   It is difficult to imagine the construction on site. In order to ensure the construction period, we insisted on working under the continuous heavy rainstorm, and it took 45 days to install in succession. Finally, we completed the task with the joint efforts of the owner and the professional installation team of Fangxing. Thank you for the full support of the owner and the hard work of the team!

In highly corrosive environments such as concentrated sulfuric acid, hydrofluoric acid, and chlor alkali, the frequent failure of traditional metal/ceramic fillers has become a chronic problem in the industry - equipment downtime, increased maintenance costs, and disrupted production continuity. How to solve this stubborn disease? PVDF corrugated packing is becoming a key solution to replace traditional packing materials in fields such as chemical engineering, environmental protection, and wet metallurgy due to its excellent corrosion resistance.      ?  Advantages: Maintain near zero corrosion to 98% concentrated sulfuric acid, 40% hydrofluoric acid, concentrated alkali, and organic solvents (measured lifespan>10 years)    ?  Technical comparison: Corrosion resistant rolled 316L stainless steel, 5 times higher than PP/PE plastic, solves the risk of collapse and fragmentation of the filling layer, and provides dual effect empowerment in structural design    ? Ripple topology optimization: gas-liquid distribution efficiency increased by 40%, pressure drop reduced by 35% (third-party flow field simulation data)    ? Lightweight Revolution: With a density of only 1.78g/cm ³, reducing tower load by over 30% and improving seismic and crack resistance performance

Wire mesh packing is currently a widely used high-efficiency packing material in various countries around the world. It is a disc-shaped packing composed of several parallel and straight metal corrugated mesh sheets arranged in a row. The corrugation has an inclination angle of 30 degrees or 45 degrees to the axis, and adjacent corrugated sheets have opposite directions. Metal wire mesh corrugated filler has a large specific surface area, high porosity, and light weight; The inclination angle of the gas phase pathway is small, regular, and the pressure decreases; Good radial diffusion, sufficient gas contact, almost no low load limit, and high operational flexibility.   (1) High number of theoretical plates, high flux, and reduced pressure; (2) Good low load performance, the theoretical number of plates increases with the decrease of gas load, and there is almost no low load limit; (3) High operational flexibility; (4) The amplification effect is not easy to understand; (5) Can meet the requirements of precision, large, and high vacuum distillation equipment. The distillation separation of difficult to separate systems, thermosensitive systems, and high-purity products provides favorable conditions. (6) Application of metal wire mesh corrugated packing (7) X-250: Precision distillation with high production intensity and few theoretical plates; (8) X-500: Vacuum distillation with thermal sensitivity and difficult to separate characteristics, especially for vacuum distillation with pressure less than 7KPa. (9) Y-700: Separation of Isotope Mixtures and Isomer Mixtures

Metal perforated corrugated packing is a new type of high-efficiency packing made from metal sheets such as stainless steel and titanium through precision punching and corrugated forming processes. It has the following significant characteristics: Large specific surface area (250-750 ㎡/m ³) 2. Porosity rate of over 95% Theoretical board quantity can reach 3-5 pieces/meter Reduce pressure to 30% -50% of traditional fillers Application Industry Description: Petrochemical industry: Ethylene/styrene separation, high-purity oxygen preparation, composite oil separation, epoxy propane separation, debutanizer, cyclohexane recovery, gasoline fractionation, atmospheric and vacuum refining, gasoline mercaptan removal, formaldehyde absorption tower, recycled ring tower, gasoline fractionation tower, catalytic reforming pre fractionation tower, refinery lubricating oil type vacuum tower, refinery catalytic cracking unit stabilization tower, aromatic hydrocarbon separation and solvent oil separation tower, depropanizer tower, pressurized distillation tower; Fertilizer industry: comprehensive gas washing tower, saturated hot water tower, ammonia recovery tower, desorption tower, replacement saturated hot water tower, decarbonization tower, methanol distillation tower, ammonia recovery tower, washing tower, ammonia air mixer in nitrate compound fertilizer projects for gas production; Environmental protection industry: devices for recovering nitrogen-containing ammonia water, waste acetone, high-purity dimethylformamide, acidic wastewater stripping tower, etc; Coal chemical industry: coking plants recover crude benzene from coke oven gas through washing towers, desulfurization towers, benzene removal towers, oil removal devices, high-pressure ammonia washing towers, water washing towers, oil removal tanks, methanol absorption towers, water gas desulfurization towers, and purification devices for stripping towers in coal to urea projects.

Project Details: Project Address: XinJiang Province, China Time:2020,June

Project Details: Project Address: XinJiang Province ,China Project Time:2018, August  Description:28000Nm3/h hydrogen production unit gas holder and desulfurization project

Project Details: Project Address:Mongolia,China Project Time: 2016, March Description:2.6 million ton coking and comprehensive utilization of coke oven gas project

Project Details： Project Address: HenNan Province,China Project Time: 2022, July Description:Nitric Acid Concentration Tower Internal Components Project

Project Details: Project Address:HenNan Province, China Project Time:2023, September Descrition:1,6 Ethylene Glycol Project
